Anticorrosive Filling Machine / Pesticide / Alcohol Based Gel Filling Machine
Equipment advantages
This machine adopts a double-row reciprocating filling system, which improves the efficiency by 80%, has a simple structure, and is universal for large and small bottles (such as the optional automatic production change system, which can realize one-touch production and precise positioning on the touch screen)
The main parameters
Number of filling heads 8-20 heads
Filling capacity 30ml-1000ml
Power 1.5Kw
Applicable bottle diameter Ф30mm-Ф100mm
Filling error ≤ ± 1%
Production speed ≤9000 bottles / hour (calculated with 100ml water as medium)
Dimensions 2000mm × 1200mm × 2300mm
Machine weight 500 kg
Air source requirements 0.4Mpa-0.6Mpa
